EXCERIA HIGH ENDURANCE G2 microSD Memory Card

Features

Product Specifications

Product Comparison

Recommended for Continuous Recording - Memory Card Made in Japan

Capacity

64GB 128GB 256GB 512GB
Max Read/Write Speed

100/50 MB/s
Speed Class
Application Performance Class
Usage

Dashboard/Surveillance camera recording

KIOXIA EXCERIA HIGH ENDURANCE G2 microSD memory cards are designed for Full HD video recording with a cumulative recording time of up to approximately 40,000 hours at 256GB. With support for UHS Speed Class 3 (U3) and Video Speed Class 30 (V30), the maximum capacity of 512GB is designed to record up to approximately 17,000 hours of 4K video. Designed specifically for dashboard and surveillance cameras, its high endurance capability makes it suitable for continuous writing and rewriting, reduces the possibility of video recording failures.

Built with BiCS FLASH™ 3D flash memory and stringent quality control in Japan, the EXCERIA HIGH ENDURANCE G2 microSD card offers both peace-of-mind and an economical option.

microSD Memory Card Lineup

Features

Endurance for Dashboard and Surveillance Camera Recording

The EXCERIA HIGH ENDURANCE G2 microSD memory cards’ specifications were designed for continuous recording for dashboard or surveillance cameras. By combining BiCS FLASH™ with stringent quality control, this feature reduces the possibility of video recording failures.

High-capacity for the Long Hours

The EXCERIA HIGH ENDURANCE G2 microSD memory cards come in capacities up to 512GB and are designed up to approximately 10 hours and 29 minutes recording of 4K video.

The Speed to Capture

The EXCERIA HIGH ENDURANCE G2 microSD memory cards provide a read speeds of up to 100 MB/s and write speeds of up to 50 MB/s^*1, making it possible for the cameras to capture unexpected guests.

Estimated Video Recording Time

Video [min]*

* Table can be scrolled horizontally.

Capacity	HD(12Mbps)	HD(17Mbps)	Full HD(21Mbps)	4K(100Mbps)
512GB	5,240	3,700	2,990	629
256GB	2,620	1,850	1,490	314
128GB	1,310	920	740	157
64GB	650	460	370	78

Recording Time: Actual recording time will vary depending on your device, resolution and compression ratio. Calculated as 1 Mbps = 1,000,000 bps.

EXCERIA HIGH ENDURANCE G2 microSD Memory Card Product Specifications

Capacity / dimensions

Capacity

64GB, 128GB, 256GB, 512GB (microSDXC)
Approximate Usable Capacity^*2

57.6GB, 115.2GB, 230.4GB, 460.8GB
Interface

UHS-I
Dimension (LxWxH)

15.0 x 11.0 x 1.0 mm
Weight

Approx. 0.3 g

Performance

Max Read Speed^*1

100 MB/s
Max Write Speed^*1

50 MB/s
UHS Speed Class^*3

U3
Video Speed Class^*3

V30
SD Speed Class^*3

C10
Application Performance Class^*4

A1
Endurance^*12

512GB: 17,000 hours (4K)
256GB: 40,000 hours (Full HD)
128GB: 20,000 hours (Full HD)
64GB: 10,000 hours (Full HD)

Operating environment / protection performance

Operating Temperature

-25 ℃ to 85 ℃ (no condensation)
Certification

RoHS compliant^*5
Waterproof

Compatible with IPX7^*6,11
X-ray Proof

ISO7816-1 compliant^*7,11
Shock Proof

Passed 5 meter drop test^*8,11
Overheating/Ignition Prevention

Electrical fuse is mounted^*9,11
ESD Immunity

Resistant to electrostatic discharge^*10,11

Compatibility

Target Applications

Dashboard cameras, surveillance cameras, and any other steady video recording devices
64GB and Over

Compatible with microSDXC supporting host devices.

Others

Services and Support

5-year limited warranty (512GB)
3-year limited warranty (64GB, 128GB, 256GB)
Included

SD Adapter LADP1
Copyright Protection (CPRM)

--

Product Info

64GB

PN: LMHE2G064GG2
EAN: 4582563859791
128GB

PN: LMHE2G128GG2
EAN: 4582563859807
256GB

PN: LMHE2G256GG2
EAN: 4582563859814
512GB

PN: LMHE2G512GG2
EAN: 4582563859821

[Reference] Estimation for SD Card Capacity (3 years of use)

Time of usage per day	4h/d	8h/d	16h/d	24h/d
1 lens Full HD (21Mbps) video recording	64GB or more	64GB or more	128GB or more	256GB or more
2 lenses Full HD (21Mbps per lens) video recording	64GB or more	128GB or more	256GB or more	512GB or more

Above table shows the estimated card capacity based on the number of lenses in in-car recording devices, dashboard cameras, and security/surveillance cameras, and it’s time of usage per day. These estimations are calculated using cumulative recording hours. Please consider the card based on estimated capacity according to your usage. If you will select a card lower than estimated capacity, we recommend to replace it earlier than warranty period.

Camera with multiple lenses might consume data size larger than one lens camera. Please check the user manual and specification of your camera.

Where to Buy

Find retailers and/or distributors near your area.

Documents & Software Download

Get the latest product briefs, user manuals, safety instructions, software, and more.

KIOXIA microSD Memory Card Comparison

* Table can be scrolled horizontally.

	EXCERIA HIGH ENDURANCE G2	EXCERIA HIGH ENDURANCE	EXCERIA PLUS G2	EXCERIA PLUS	EXCERIA G2	EXCERIA
Video Recording	4K	4K (64, 128, 256, 512GB) Full HD (32GB)	4K	4K	4K	Full HD
Max Read/Write Speed^*1 (MB/s)	100/50	100/85 (256, 512GB) 100/65 (64, 128GB) 100/30 (32GB)	100/90 (256, 512GB, 1TB, 2TB) 100/65 (64, 128GB)	100/85 (256, 512GB, 1TB) 100/65 (64, 128GB) 98/65 (32GB)	100/50	100/--
Capacity^*2	64, 128, 256, 512GB	32, 64, 128, 256, 512GB	64, 128, 256, 512GB, 1TB, 2TB	32, 64, 128, 256, 512GB, 1TB	32, 64, 128, 256, 512GB, 1TB	16, 32, 64, 128, 256GB
SD Interface	UHS-I	UHS-I	UHS-I	UHS-I	UHS-I	UHS-I
SD Speed Class^*3	C10	C10	C10	C10	C10	C10
UHS Speed Class^*3	U3	U3 (64, 128, 256, 512GB) U1 (32GB)	U3	U3	U3	U1
Video Speed Class^*3	V30	V30 (64, 128, 256, 512GB) V10 (32GB)	V30	V30	V30	--
Application Performance Class^*4	A1	A1	A1	A1	A1	--
Waterproof^*6,11	Yes	Yes	Yes	Yes	Yes	Yes
X-ray Proof^*7,11	Yes	Yes	Yes	Yes	Yes	Yes
Shock Proof^*8,11	Yes	Yes	Yes	Yes	Yes	Yes
Overheating / Ignition Prevention^*9,11	Yes	Yes	Yes	Yes	Yes	Yes
ESD Immunity^*10,11	Yes	Yes	Yes	Yes	Yes	Yes
CPRM	--	Supported	--	Supported	--	--
Endurance	High	High	Standard	Standard	Standard	Standard
Warranty Period	3 or 5 years	3 or 5 years	5 years	5 years	5 years	5 years

1 MB/s is calculated as 1,000,000 bytes/s. These values are the best values obtained in a specific test environment at KIOXIA Corporation and KIOXIA Corporation warrant neither read nor write speeds in individual devices. Read and write speed may vary depending on a device used and file size read or written. The write speed is lower than the read speed.
Capacity is based on installed flash memory and not user available memory as part of the memory is used for management functions. Available user area are as listed above (1GB = 1,073,741,824 bytes).
Speed classes indicate the results under the test conditions specified by SD Association.
Application Performance Class is based on the result measured under the conditions specified by SD Association.
KIOXIA Corporation defines “RoHS Compatible” products as products that either ( i ) contain no more than a maximum concentration value of 0.1% by weight in Homogeneous Materials for lead, mercury, hexavalent chromium, polybrominated biphenyls (PBBs), polybrominated diphenyl ethers (PBDEs), bis(2-ethylhexyl) phthalate (DEHP), dibutyl phthalate (DBP), benzyl butyl phthalate (BBP) and diisobutyl phthalate (DIBP) and of 0.01% by weight in Homogeneous Materials for cadmium; or ( ii ) fall within any of the application exemptions set forth in the Annex to the RoHS Directive(*). This does not mean that Kioxia Corporation products labeled “RoHS COMPATIBLE” are entirely free of substances controlled by the RoHS Directive and does not constitute a warranty or guarantee that such products will comply with the specific laws and/or regulations adopted in any particular jurisdiction.
*RoHS Directive: KIOXIA Corporation defines “RoHS Directive” as the DIRECTIVE 2011/65/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
According to IPX7 standard, the product (only card) can function, after it is submerged quietly and left for 30minutes in static tap water at room temperature(15 °C to 35 °C) and in depth of 1m and then it is taken out of the water.
According to ISO7816-1 standard, the product can function, after contaminating this product on 0.1 Gy of X-ray.
The product (only card) can function, after carrying out the gravity fall of this product (only card) from 5 m in height. ( Based on KIOXIA Corporation's test results.)
KIOXIA Corporation does not warrant that the function of the fuse in the card will be error free, nor does it warrant that any data stored on the card will remain accessible or uncorrupted. Turn off the device immediately in case the card overheats and/or emits a burning smell.
ESD test environment stipulated by IEC61000-4-2 150-pF energy storage capacitor, 330-Ω discharge resistor, ±15-kV air discharge.
KIOXIA Corporation does not warrant any data stored on the product.
Designed target of accumulated time based on Full HD (1920x1080) video content recorded at 21Mbps or 4K (3840x2160) video content recorded at 100 Mbps. Results may vary depending on a device and other conditions.
Operation is not warranted on all devices. Please be sure to check the user’s manual of your host device for product compatibility.
